Crestron Ultimate OD6T 6 in. 2-Way Outdoor Speaker with Ribbon Tweeter

The OD6T brings a 3 in. planar magnetic ribbon tweeter to an outdoor speaker, which is unusual and audible: it crosses over at 2 kHz into a 5.25 in. glass fibre woofer and covers 120 Hz to 20 kHz at 3 dB with 110 degrees of horizontal and 75 degrees of vertical dispersion. Power handling is 150 W program and 300 W peak at 8 ohms, and 70 V and 100 V transformer taps at 75 W and 150 W make it equally usable on a distributed line.

The enclosure is colour-molded composite with a UV-treated HDPE baffle and an electroplated, powder-coated steel grille, rated IP65 for water. It mounts on a ground stake, on a tree, or on a surface, and terminates in a 24 in. 14 AWG pigtail with waterproof wire nuts. Bronze textured suits planting beds; the primed version is meant to be painted to match a wall or soffit.

Woofer	5.25 in. (133 mm) glass fiber
Tweeter	3 in. (76 mm) planar magnetic ribbon
Crossover	Passive custom 12 dB/oct at 2 kHz
Frequency Response	120 Hz to 20 kHz (+/- 3 dB), 95 Hz to 25 kHz (+/- 10 dB)
Power Handling	150 W program, 300 W peak at 8 ohms; taps at 75 W on 70 V and 150 W on 100 V
Coverage and Sensitivity	110 degrees horizontal, 75 degrees vertical, 86 dB at 1 W/1 m
Input	24 in. x 14 AWG pigtail with waterproof wire nuts
Construction	Color-molded composite enclosure, UV treated HDPE baffle, steel grille, IP65 rated for water
Dimensions	9.25 in. H x 6.65 in. W x 10.43 in. D (235 x 169 x 265 mm), 6.8 lb (3.1 kg)
