Crestron DM-NAX-AUD-IO DM NAX Audio-over-IP Converter with Balanced/Unbalanced Line-Level Audio

The Crestron DM-NAX-AUD-IO is a DM NAX Audio-over-IP Converter with Balanced/Unbalanced Line-Level Audio Input and Output. DM NAX moves audio around a building over the same network that carries the video, so a zone becomes a switch port rather than a home run back to a rack of amplifiers.

Inputs accept Balanced/unbalanced stereo analog line-level; DM NAX/AES67 audio-over-IP. The chassis is metal, black and silver finish. PoE: IEEE 802.3af Class 0 (12.95 W) compliant; Compatible with IEEE 802.3af compliant Ethernet switch or third-party PoE compliant PSE. It is set up and monitored from the same Crestron control program and XiO Cloud account as the rest of the estate.

Input Signal Types	Balanced/unbalanced stereo analog line-level; DM NAX/AES67 audio-over-IP
Frequency Response (at line-level output)	20 Hz to 20 kHz +/-0.5 dB
Ethernet	For control and PoE, AoIP, and/or console, 100/1000 Mbps, auto-switching, auto-negotiating, auto-discovery, full/half duplex, DHCP
PoE	IEEE 802.3af Class 0 (12.95 W) compliant; Compatible with IEEE 802.3af compliant Ethernet switch or third-party PoE compliant PSE
ETHERNET PoE	(1) 8-pin RJ-45 connector, female; 100BASE-TX/1000BASE-T Ethernet port;
Mounting	Mountable on the following via included hardware: 1-gang U.S. electrical box or plaster ring (not included), 3.5 in. (89 mm) electrical box depth recommended; Rack rail; Surface mount
Chassis	Metal, black and silver finish
Heat Dissipation	17 BTU/hr
