BZBGear BG-BSHA Streaming Box Camera

A box camera solves the problem a PTZ cannot: a fixed, framed shot from a bracket, a rail or a lectern, with no motor noise and nothing to knock out of alignment. The BSHA puts 3G-SDI, HDMI and an IP stream out together from a 1/2.8 inch Exmor CMOS sensor, and takes a 3.5 mm stereo input so room audio rides along with the picture.

The body is 70 mm square and weighs under half a pound, so it mounts almost anywhere and takes a standard lens shroud or housing. Zoom and camera settings are driven over RS-485 or RS-232 using VISCA or Pelco D/P, which lets it sit on the same control bus as the PTZ heads in the rest of the rack.

  • Dimensions (W x H x L)2.8 x 2.8 x 4.8in [70 x 70 x 122mm]
  • Video outputs3G-SDI / HDMI / IP Streaming
  • Audio input3.5mm Stereo Mini
  • Control interfaceRS485 / RS232
  • Image sensor1/2.8" Exmor CMOS Sensor, 2.38MP
Image Sensor1/2.8" Exmor CMOS Sensor, 2.38MP
Optical Zoom (by model)20X/30X Optical, 12X Digital Zoom
Frame Rates1080p@60Hz/50/30/25, 1080i@60Hz/50/30/25, 720p@60Hz/50
ApertureF=1.6(W)-3.5(T)
Video Outputs3G- / / IP Streaming
Audio Input3.5mm Stereo Mini
Control InterfaceRS485 / RS232
Dimensions (W x H x L)2.8 x 2.8 x 4.8in [70 x 70 x 122mm]
Weight0.44 lbs [0.2kg]
Field of View2.9°(T)-65°(W)
How to Livestream on YouTube with BZBGEAR BG-B20SHA 20X Zoom Box Camera - Full Overview and Setup!
4items in the box
  • BG-BSHA camera
  • 12V/2.0A DC power adapter
  • Power cable
  • User manual
