Biamp Commercial Audio REVAMP2120T Power Amplifier

The Biamp Commercial Audio REVAMP2120T is a power amplifier built for retail and hospitality installations. Frequency response is quoted at 50 - 20 kHz.

Power handling is rated at 115 - 230 VAC. Rated output power is Dynamic output power 4 ohms: 2 x 120 watts; Dynamic output power 8 ohms: 2 x 60 watts; Dynamic output power bridged 8 ohms: 240watts. Nominal impedance is 4 ohms; Minimum impedance load bridged per channel: 8 ohms; Applicable low impedance: yes. Power consumption is 300 watts.

Frequency Response50 - 20 kHz
PowerPower supply: 115 - 230 VAC
ImpedanceMinimum impedance load per channel: 4 ohms; Minimum impedance load bridged per channel: 8 ohms; Applicable low impedance: yes
Power OutputDynamic output power 4 ohms: 2 x 120 watts; Dynamic output power 8 ohms: 2 x 60 watts; Dynamic output power bridged 8 ohms: 240watts
Power Consumption300 watts
Weight13.44 lbs (6.1 kg)
Dimensions (H x W x D)1.73 inches (44 mm); Rack units: 1U 1.73 inches (44 mm) x Rack Mounting: 19 inches (483 mm) x 9.40 inches (239 mm (including front); 9.05 inches (230 mm (build in)
CoolingConvectional
