Biamp Cambridge Qt X 600D Sound Masking Generator

The Biamp Cambridge Qt X 600D is a sound masking generator built for sound masking and speech privacy systems. Inputs are Captive Screw Terminal; Number of Inputs: 2 (Mono); Input Level: +24dBu (12.3VRMS max); Input Gain Range: 6dB steps.

Power handling is rated at Operating Voltage: 100-240VAC 50/60Hz. Rated output power is 24VDC @ 2.7A. Audio: Output Connections: (6) RJ-45. Control connection is Connector Type: Captive Screw Terminal; Input Type: Contact Closure (Normally Open); Number of Inputs: 2.

Power	Operating Voltage: 100-240VAC 50/60Hz
Input Type	Input Connector Type: Captive Screw Terminal; Number of Inputs: 2 (Mono); Input Level: +24dBu (12.3VRMS max); Input Gain Range: 6dB steps
Audio	Output Connections: (6) RJ-45
Control	Remote Control: Connector Type: Captive Screw Terminal; Input Type: Contact Closure (Normally Open); Number of Inputs: 2; Output Type: Logic Status (5VDC)
Power Output	24VDC @ 2.7A
Power Consumption	Max. Power Consumption (24VDC): 30W
Dimensions (H x W x D)	3.5 inches (89mm) x 11 inches (279mm) x 3.8 inches (97mm)
Included Accessories	ACT Hole Saw, Wall Bracket
