Name: Biamp Cambridge Qt X 805D Sound Masking Generator
Brand: Biamp
Price: 3180.00 USD
Availability: InStock

The Biamp Cambridge Qt X 805D is a sound masking generator built for sound masking and speech privacy systems. Inputs are Captive Screw Terminal; Number of Inputs: 2 (Stereo or Mono); Input Level: +24dBu (12.3VRMS max); Input Gain Range: 6dB steps.

Power handling is rated at Operating Voltage: 100-240VAC 50/60Hz; Current Draw: 0.5A; Output: 48VDC @1.04A (50W Max); Max. Power Consumption (48VDC): 24W. Audio: Output Connector Type: Captive Screw Terminal; Number of Amplified Outputs: 8; Nominal Output Impedance: 4 ohms. Control connection is Connector Type: Captive Screw Terminal; Input Type: Contact Closure (Normally Open); Number of Inputs: 2. In the box: Plenum T-bar mount with wire hanger positions.

Power	Power Supply; Operating Voltage: 100-240VAC 50/60Hz; Current Draw: 0.5A; Output: 48VDC @1.04A (50W Max); Max. Power Consumption (48VDC): 24W
Input Type	Input Connector Type: Captive Screw Terminal; Number of Inputs: 2 (Stereo or Mono); Input Level: +24dBu (12.3VRMS max); Input Gain Range: 6dB steps
Audio	Amplified Audio Outputs: Output Connector Type: Captive Screw Terminal; Number of Amplified Outputs: 8; Nominal Output Impedance: 4 ohms; Pre-Amplifier Audio Outputs
Control	Remote Control: Connector Type: Captive Screw Terminal; Input Type: Contact Closure (Normally Open); Number of Inputs: 2; Output Type: Logic Status (5VDC)
Included Accessories	Plenum T-bar mount with wire hanger positions
Ambient Operating Temperature Range	40 - 104 deg F (4 - 40 deg C)
Dimensions (H x W x D)	3.5 inches (89mm) x 14 5/8 inches (371.5mm) x 3.8 inches (97mm)
Humidity	0-95% relative humidity (non-condensing)
