Biamp BMA 360D White Ceiling Tile

The Biamp BMA 360D White is a ceiling tile built for business audio and installed sound systems. Power handling is rated at PoE injector or equivalent; Thermal: 270 BTU/hr at max power.

Network connections are Dante and AES67. Power consumption is 100-240 VAC, 50/60 Hz 23 Watt typical without speaker amp 55 W at 1/3 power x 4 @ 1 kHz. Mounting provision: Ceiling Mount: 24 in drop-ceiling grid; VESA Mount ready: 100 mm hole pattern, M 4 x 10 mm.

Power	Power Source: PoE injector or equivalent; Thermal: 270 BTU/hr at max power
Network Connection(s)	Network Media Protocols: Dante and AES67
Power Consumption	100-240 VAC, 50/60 Hz 23 Watt typical without speaker amp 55 W at 1/3 power x 4 @ 1 kHz
Mounting	Ceiling Mount: 24 in drop-ceiling grid; VESA Mount ready: 100 mm hole pattern, M 4 x 10 mm
Weight	11.1 lbs (5.0 kg); Shipping Weight: 14.2 lbs (6.4 kg)
Operating	Operating Temperature: 14 deg F/-10 deg C to 104 deg F/40 deg C ambient temperature
Dimensions (H x W x D)	23.7 inches x 23.7 inches x 2.1 inches
PoE / PoE+ Ports	Port Type: RJ-45 PoE++ power Power on all pairs 56 V 90 W IEEE 802.3 bt compliant devices or equivalent, Mode A and B, Midspan
