Black Box AVSP-HDMI1X2 HDMI Splitter with Audio, 1 x 2
A 1 x 2 splitter that duplicates one HDMI source across two outputs without distortion or attenuation. Connect the cables, apply power, and both screens show the same picture up to 16.4 feet (5 m) away; cascade units when you need more outputs than one box provides.
It is fully HDCP compliant and Blu-ray ready, supports EDID display information, and handles UXGA 1600 x 1200, WUXGA 1920 x 1200 and Full HD 1080p. Audio travels either embedded in HDMI or through the separate 3.5 mm analogue jacks. LEDs show activity on each port, and the unit drops into power-save when the input signal disappears. Nothing to install - no software, no interface cards.
| Configuration | 1 x 2 - one HDMI input, two outputs |
|---|---|
| Resolutions | UXGA 1600 x 1200, WUXGA 1920 x 1200, Full HD 1080p |
| Content protection | Fully HDCP compliant, Blu-ray ready |
| EDID | Supports EDID display information |
| Audio | Embedded HDMI audio or separate 3.5 mm analog jacks |
| Output distance | Up to 16.4 ft (5 m) |
| Expansion | Cascadable for additional outputs |
| Indicators and power | Per-port activity LEDs; automatic power-save on signal loss |
| Ships with | Splitter, AC power adapter with cord, foot pads, user manual |
