Avantone Pro Gauss 7 Active Studio Monitors Bi-Amped 7 Inch Active Monitor

Gauss 7 is an active two-way monitor built around a 7 inch ferrite-motor woofer and a 2.5 inch AMT (air motion transformer) tweeter, bi-amped in Class D at 120 W to the low end and 60 W to the high end. The bass-reflex, hybrid MDF cabinet with real wood veneer is rated 30 Hz to 22 kHz, with 103 dB peak SPL and 0.5% THD.

Front-panel controls cover a +/-6 dB gain trim, a three-position acoustic placement switch (-4 dB, -2 dB, 0 dB) for close-to-wall setups, and a high-trim switch (-2 dB, 0 dB, +2 dB) for the tweeter. Inputs are balanced TRS/XLR, and the universal 110-240V power supply draws under 0.5 W in standby.

Type	Active, two-way (pair)
Frequency Response	30 Hz - 22,000 Hz
LF Driver	7 in (178 mm) ferrite motor
HF Driver	2.5 in (65 mm) AMT
Amplifier Power	120 W LF / 60 W HF, bi-amped Class D
Max SPL	103 dB peak
Controls	Gain (+/-6 dB), acoustic placement, high trim
Inputs	Balanced TRS / XLR
Power	110-240V, 50/60 Hz; under 0.5 W standby, 250 W full output
Dimensions / Weight	15 in H x 9.25 in W x 8.35 in D; 18 lb each
