AUDAC PSD241 Power supply 24V DC 1.67A ABS

The PSD241 is AUDAC's power supply 24V DC 1.67A ABS and 80,16 W peak. The dc outputs current is 1.67 A.

Inputs land on IEC C14 Connector and outputs on Tinned cable ends (Red '+' / Black '-' ). The housing is ABS. It measures 3.94 x 1.97 x 1.30 in (W x H x D) and weighs 0.42 lb.

Inputs Connector	IEC C14 Connector
Outputs Connector	Tinned cable ends (Red '+' / Black '-' )
DC Outputs current	1.67 A
DC Outputs Voltage	+24V DC +/- 5%
Regulation	22.80Vmin ~ 24.00Vtyp ~ 25.20Vmax
Peak power handling	80,16 W
Program power handling	40.08 W
Ripple and Noise	240 mV
