AUDAC EPA502 Dual-channel Class-D amplifier 2 x 500W
The EPA502 is AUDAC's dual-channel Class-D amplifier 2 x 500W over a 20 Hz - 20 kHz response. The continuous power (aes) @ 4 ohms stereo is 2 x 500 W.
Inputs land on XLR female with Male Linkthrough and outputs on Speakon compatible & 2-pin Euro Terminal Block (5.08 mm). Power comes from Switching mode. The housing is Steel. It measures 18.98 x 1.73 x 12.99 in (W x H x D) and weighs 10.36 lb.
| Continuous power (AES) @ 4 ohms Stereo | 2 x 500 W |
|---|---|
| Continuous power (AES) @ 8 ohms Stereo | 2 x 300 W |
| Continuous power (AES) @ 8 ohms Bridge | 1000 W |
| Frequency Response (+/- 3 dB) | 20 Hz - 20 kHz |
| Frequency Signal / Noise | > 90 dB |
| Frequency THD+N (@ 1 kHz) | < 0.1% |
| Frequency Crosstalk (@ 1 kHz) | > 70 dB |
| Frequency Technology | Class-D |
