Audio-Technica ATW-T1406 System 20 PRO Boundary Microphone Transmitter
The ATW-T1406 is a boundary microphone with a System 20 PRO transmitter built into it, so a conference table, a stage floor or an altar becomes a wireless channel with nothing running to it. Removing the cable is usually the whole point: a table can be reconfigured between meetings without an AV call.
It operates on 2,402 to 2,480 MHz with AES128 encryption, passing 20 to 20,000 Hz audio at 24-bit/48 kHz with 2.8ms of latency. It pairs with the ATW-R1440 receiver, and a system supports 10 channels.
| Operating Frequencies | 2,402 to 2,480 MHz |
|---|---|
| System Frequency Response | 20 to 20,000 Hz Varies depending on the microphone to be installed. |
| Dynamic Range | 120 dB (A-weighted), typical |
| Total Harmonic Distortion | < 0.05%, typical |
| Maximum Simultaneous Use (recommended) | Standard: 10 channels HD mode: 20 channels It depends on the region and environment. |
| Delay | Standard: 2.8ms HD mode: 6.7ms |
| Audio Sampling Rate | Standard: 24-bit/48 kHz HD mode: 24-bit/48 kHz |
| Encryption Method | AES128 |
