American DJ DMX Operator Pro 136-Channel Lighting Controller

The DMX Operator Pro addresses 136 DMX channels: 128 spread across eight intelligent fixtures at 16 channels each, plus 8 dedicated par can channels. Eight faders sit under your hands for direct level control, which is what makes it quick to busk rather than only play back.

It stores 96 scenes and 8 chases with per-chase fade and speed, and writes the whole show to a 32 MB CompactFlash card so a controller swap does not cost you the rig. DMX patching, fixture grouping and a Step/Mix sequence function handle the addressing side, and there is a Tap Sync button plus a dedicated fog machine trigger. A built-in microphone and MIDI input let the console follow the room or the desk.

DMX Channels136 total: 128 for intelligent fixtures, 8 for par cans
Fixtures8 fixtures at 16 DMX channels each
Scenes96 programmable
Chases8 programmable with fade and speed control
MemoryBackup to 32 MB CompactFlash card
Control InputsMIDI controllable, built-in microphone
FunctionsDMX patching, Fixture Group, Step/Mix Sequence, Tap Sync
ExtrasFog machine trigger button
DMX Operator Pro Walkthrough, Part 1
DMX Operator Pro Walkthrough, Part 2
