Whirlwind PLR-PS1T Rack Power Pack, powerCON TRUE1

The PLR-PS1T is a one rack space power pack for the top of a touring rack. It has a powercon true1 20 a inlet and outlet and five 15 A Hubbell tamper-resistant duplex outlets, protected by a 15 A hydraulic and magnetic circuit breaker rather than a thermal one, which is what keeps it from nuisance-tripping when a rack full of amplifiers wakes up.

Surge suppression and EMI filtering are built in: better than 50 dB differential mode and better than 40 dB common mode from 200 kHz to 10 MHz. Maximum inrush current is 91 A. It is 1 RU by 6 in. deep measured from the ears to the rear panel, weighs 5 lb, and like every Power Link product it carries a 5 year warranty.

Type	Rack mount AC power pack
Inlet and outlet	powerCON TRUE1 20 A inlet and outlet
Outlets	Five 15 A Hubbell tamper-resistant duplex
Breaker	15 A hydraulic / magnetic
EMI filtering	Differential mode > 50 dB, common mode > 40 dB, 200 kHz to 10 MHz
Max inrush current	91 A
Format	1 RU, 6 in. deep ears to rear panel, 5 lb
Warranty	5 years
