Shure SLXD4
The SLXD4 is the single-channel receiver at the heart of Shure's SLX-D digital wireless systems, pairing with an SLXD1 bodypack or SLXD2 handheld to deliver transparent 24-bit digital audio across an extended 20 Hz to 20 kHz range. Digital predictive switching diversity and 120 dB of dynamic range keep the signal clean and dropout-free through a working set.
Setup stays quick: IR scan and sync pairs a transmitter in seconds, and 44 MHz of tuning bandwidth opens 32 channels per band, with up to 10 compatible systems in a 6 MHz TV channel or 12 in an 8 MHz channel. The rugged metal chassis includes an AC power supply and is offered in the G58 (470-514 MHz), H55 (514-558 MHz), and J52 (558-616 MHz) bands.
| Audio | Transparent 24-bit digital |
|---|---|
| Frequency Range | 20 Hz to 20 kHz (microphone dependent) |
| Dynamic Range | 120 dB |
| Diversity | Digital predictive switching |
| Tuning Bandwidth | 44 MHz (region dependent) |
| Channels | 32 per band; up to 10 systems per 6 MHz TV band, 12 per 8 MHz |
| Pairing | IR scan and sync |
| Included | AC power supply |
| Frequency Bands | G58 (470-514 MHz), H55 (514-558 MHz), J52 (558-616 MHz) |
