SmallHD Cine 5 5-inch Camera Monitor
The Cine 5 is a 5-inch 1920x1080 touchscreen at 440 PPI that pushes 2000 nits, so it holds up in bright exteriors while staying small enough to live on the front of a cinema build. Its 10-bit panel and PageOS colour tools make it a serious focus and exposure monitor for a first AC or camera operator, not just a framing screen.
It accepts 3G-SDI and HDMI 2.0 (up to 4Kp30) with loop and clean outputs, and a locking USB port keeps camera-control and accessory connections from pulling loose on the move. Power is 10-34V DC over a 2-pin locking connector, and the SmallHD tool set covers scopes, false colour, focus assist, and custom LUTs.
| Display | 5-inch 1920 x 1080 touchscreen, 440 PPI |
|---|---|
| Brightness | 2000 nits |
| Colour | 10-bit |
| Video Inputs | 1x 3G-SDI, 1x HDMI 2.0 (up to 4Kp30) |
| Video Outputs | 1x 3G-SDI (loop), 1x HDMI 2.0 |
| Audio | 1x 3.5mm stereo headphone jack |
| Power | 2-pin locking, 10-34V DC, 1.6A |
| Data | SD card slot, Micro USB, locking USB |
