RGBlink MSP 305 Bidirectional 3G-SDI and HDMI Converter
The MSP 305 converts in both directions at once. It has an HDMI input feeding an SDI output and an SDI input feeding an HDMI output, so a single small box handles both halves of the conversion a mixed HDMI and SDI setup keeps needing.
It runs at up to 1080p60 with a 2.970 Gbit/s bit rate, auto-detecting between 3G, HD and SD SDI, and passes embedded audio through in both directions. HDMI 1.3 and 3G-SDI are both supported. Practically it means a long SDI run can carry an HDMI source out and bring a return feed back on the same piece of hardware.
| Connectors Input HDM | 1xHDMI Type A |
|---|---|
| SD | 1xBNC |
| Output HDM | 1xHDMI Type A |
| Performance Input Resolutions SMPTE | 720p@23.98/24/25/29.97/30/50/59.94/60 | 1080i@23.98/24/25/29.97/30/50/59.94/60 |
| VESA | 800x600@60 | 1024x768@60 | 1280x768@60 | 1280x1024@60 | 1366x768@60 |
| Output Resolutions SMPTE | 720p@23.98/24/25/29.97/30/50/59.94/60 | 1080i@23.98/24/25/29.97/30/50/59.94/60 |
| Supported Standard | SDI SMPTE 425M,SMPTE 424M,SMPTE 292M,SMPTE 259M-C HDMI 1.3 |
| Power Input Voltage | DC 5-12V |
