RCF NXL 14-A Line Array Column
The NXL 14-A is the smallest active speaker in RCF's NXL series, pairing two 6-inch neodymium woofers with a 1.75-inch neodymium compression driver with a PKX dome. A 2100W peak Class-D bi-amp (1400W LF, 700W HF) reaches 128 dB SPL across 70 Hz to 20 kHz, with wide 100 by 70 degree coverage suited to vocal reproduction, compact live systems, and fill duty.
It pairs naturally with RCF's SUB series subwoofers for a small full-range rig, or works in immersive audio setups where several compact boxes cover different zones. Combo XLR/jack inputs, an XLR output and powerCON TRUE1 TOP in/out cover wiring, and the plywood cabinet with polyurea paint ships in black or white.
| Configuration | Two-way active speaker |
|---|---|
| Woofers | 2 x 6" neodymium (2.0" voice coil) |
| Compression Driver | 1.75" neodymium, PKX dome (1.0" voice coil) |
| Amplifier Power | 2100W peak (1400W LF + 700W HF) |
| Max SPL | 128 dB @ 1m |
| Frequency Response | 70 - 20,000 Hz |
| Coverage | 100 x 70 degrees |
| Connectors | Combo XLR/jack input, XLR output, powerCON TRUE1 TOP |
| Weight | 12.8 kg (28.22 lbs) |
