Panasonic Lumix S 24-60mm F2.8 L-Mount Lens
The Lumix S 24-60mm F2.8 is a constant F2.8 standard zoom light enough to live on the camera. Built to the L-Mount standard shared by Panasonic, Leica and Sigma, it uses 14 elements in 12 groups (3 aspherical, 1 UED, 2 ED) and covers 84 - 40 degrees.
Maximum aperture is F2.8 with a minimum of F22, and the iris carries 9 blades in a circular pattern. It focuses to 0.19m (24mm to 30mm) / 0.33m (tele), from the imaging plane for a maximum magnification of 0.30x at 30mm, takes 77mm filters, and measures 84.0mm max diameter x approx. 99.9mm length at approx. 544g (excluding hood and caps). The barrel is dust and splash resistant.
| Model | S-E2460 |
|---|---|
| Mount | L-Mount (Leica Camera AG standard) |
| Focal Length | f=24-60mm |
| Maximum Aperture | F2.8 |
| Minimum Aperture | F22 |
| Lens Construction | 14 elements in 12 groups (3 aspherical, 1 UED, 2 ED) |
| Diaphragm | 9 blades, circular aperture diaphragm |
| Minimum Focus Distance | 0.19m (24mm to 30mm) / 0.33m (tele), from the imaging plane |
| Maximum Magnification | 0.30x at 30mm |
| Filter Size | 77mm |
| Angle of View | 84 - 40 degrees |
| Dust and Splash Resistant | Yes |
| Dimensions | 84.0mm max diameter x approx. 99.9mm length |
| Weight | Approx. 544g (excluding hood and caps) |
