Kramer RCP-7272 Remote Panel for 7272HD-3G
The Kramer RCP-7272 is the remote control panel for the 7272HD-3G matrix switcher, giving an operator 72x72 routing control away from the matrix. It connects directly to the switcher or over a network.
It has 79 back-lit, multi-color LED buttons, 72 for inputs and outputs and 7 for control, and connects through a 10/100 Base-T Ethernet port. It runs on 12 V DC, draws 4.8 W maximum, accepts 100 to 240 V AC at 50 to 60 Hz, operates from 0 to 45 C and fits a standard 19-inch rack in 2U.
| OPERATING TEMPERATURE | 0-45C |
|---|---|
| AC INPUT RANGE | 100-240V, 50-60Hz |
| MAX AC POWER | 4.8W |
| ETHERNET (1) | 10/100 Base-T (RJ-45) |
| Buttons | 79 back-lit multi-color LED (72 I/O, 7 control) |
| Matrix | 72x72 |
| Rack Size | 2U |
