FOR.A HVS-110 1M/E Video Production Switcher

The HVS-110 folds FOR.A's Hanabi 1M/E switcher into a single integrated chassis, combining the main unit and control panel in one compact body built for OB vans, broadcast helicopters, and other tight installs. It comes standard with 12 HD/SD-SDI inputs and 8 HD/SD-SDI plus 1 HDMI output, all fixed on the rear panel. Frame synchronizers on eight inputs and re-sizing engines on four let it mix synchronous and asynchronous HD and SD sources without external gear.

Despite the smaller footprint it carries the same core toolset as the HVS-100: 2 keyers, 2 downstream keyers, four 2.5D DVE engines, an assignable advanced chroma keyer, two still/clip stores holding up to 227 frames of HD each, and a 16-channel multi-viewer with 20 split-screen layouts. Operators can control it over the built-in web server from a PC or tablet, with 100-event memory and macros for fast recall during live production. The unit includes the HVS-100EXP3G 3Gbps expansion software and HVS-100ED editor interface software; an optional HVS-110PSM AC adaptor provides a redundant power source.
