Elation ZCL 360i LED Lighting Fixture
The Elation ZCL 360i is an LED lighting fixture from Elation. Elation lists the source as 90W RGBW 4-in-1 LED, 100,000 Hour Average LED Life. Published photometric data: 11,123 LUX 1,033 FC @9.8' (3m) (4 deg Min Zoom) Full ON, 483 LUX 45 FC @9.8' (3m) (44 deg Max Zoom) Full ON.
Control / connections covers (3) DMX Channel Modes (21 Total Channels), RDM (Remote Device Management), (7) Button Touch Control Panel. Listed length: 8.74" (222.1mm). Ordering code ZCL360I.
| Source | 90W RGBW 4-in-1 LED, 100,000 Hour Average LED Life |
|---|---|
| Photometric Data | 11,123 LUX 1,033 FC @9.8' (3m) (4 deg Min Zoom) Full ON, 483 LUX 45 FC @9.8' (3m) (44 deg Max Zoom) Full ON |
| Effects | RGBW Color Mixing, 4 deg - 44 deg Beam Zoom Range, Variable Dimming Curves, Electronic Strobe and Dimming (0% - 100%), 64 Color Presets and 14 Unique Color Macros |
| Control / Connections | (3) DMX Channel Modes (21 Total Channels), RDM (Remote Device Management), (7) Button Touch Control Panel, Full Color 180 deg Reversible LCD Menu Display, 8 / 16 Bit Resolution Adjustable... |
| Length | 8.74" (222.1mm) |
| Width | 7.31" (186mm) |
| Vertical Height | 13.22" (336mm) |
| Weight | 13 lbs. (5.9 kg) |
