Elation UNI BAR LED Bar Fixture

The Elation UNI BAR is an LED bar from Elation. Rated width: 3.23" (82mm). Rated vertical height: 2.63" (66.8mm).

Control / connections covers 1 DMX Channel, 3-Button Control Panel, LCD Menu Display, On-board HTP Dimming Control Dial, Input for Optional Analog HTP Dimmer. Electrical is quoted at AC 120V - 60Hz / 10A Max Total Output. Listed length: 7.83" (200mm). Ordering code UNIBAR.

Control / Connections	1 DMX Channel, 3-Button Control Panel, LCD Menu Display, On-board HTP Dimming Control Dial, Input for Optional Analog HTP Dimmer, 2 Edison 3-prong Outputs (10A Max Total Output), 5pin DMX...
Length	7.83" (200mm)
Width	3.23" (82mm)
Vertical Height	2.63" (66.8mm)
Weight	2.4 lbs. (1.1 kg)
Electrical	AC 120V - 60Hz / 10A Max Total Output
