Elation eNode8 Pro DMX Data Distribution Node

Manufacturer has discontinued this model. Call or email for remaining stock and lead time.

The Elation eNode8 Pro is a DMX data distribution node from Elation. Rated width: 6.3" (160mm). Rated vertical height: 1.7" (44mm).

Control / connections covers 8-Universes, DMX, RDM, Art-Net, and sACN Protocol Support, DMX Bilateral Conversion, sACN Auto-Detection, Auto MDI/MDIX. Electrical / thermal is quoted at AC 100-240V - 50/60Hz, 7W Max Power Consumption, 35.6 degF (2 degC) to 113 degF (45 degC). Listed length: 19.0" (482mm). Ordering code ENODE 8 PRO.

Control / Connections8-Universes, DMX, RDM, Art-Net, and sACN Protocol Support, DMX Bilateral Conversion, sACN Auto-Detection, Auto MDI/MDIX, DMX Splitter Function (1 Input / 3 Outputs), Broadcast Mode (One D...
Length19.0" (482mm)
Width6.3" (160mm)
Vertical Height1.7" (44mm)
Weight4.6 lbs. (2.1kg)
Electrical / ThermalAC 100-240V - 50/60Hz, 7W Max Power Consumption, 35.6 degF (2 degC) to 113 degF (45 degC)
ApprovalsCE | cETLus | IP65

Resources and support

Compatibility helpCall (201) 791-1400 to confirm signal format, connections, and workflow fit. Elation product familyContinue browsing the full Elation range we carry.
