Countryman Isomax 2 All-Purpose Microphone
The Isomax 2 is a miniature directional mic whose patterns are frequency-independent: a cardioid stays cardioid and a hypercardioid keeps its rejection into the low end, where most miniature directional mics quietly become omnidirectional as the frequency drops and a cardioid clip-on can still pick up the drummer behind it. Combined with a 150 dB SPL overload point, that makes it a genuine all-purpose capsule for strings, winds, brass, and percussion, and for placement work where a mic has to reject the room as much as capture the source.
The capsule measures 8 by 16 by 4 mm excluding the strain relief and is offered in omnidirectional, cardioid, and hypercardioid patterns in standard or high gain. Output is 600 Ohms balanced and transformerless, tightly specified at plus or minus 2%, and it drives a load without distortion at full rated SPL. Powering is 6 V to 50 V phantom at 4 mA. Wireless configurations ship with a 5 ft cable and hardwired configurations with 10 ft, and Countryman's flute, saxophone and horn, guitar, and stage mounts cover the common instrument placements.
- Dimensions5/16 in x 5/8 in x 5/32 in excluding strain relief
- Output Impedance600 Ohms +/- 2% balanced, transformerless
- Polar PatternsOmnidirectional, cardioid, or hypercardioid
- Frequency ResponseOmnidirectional: 20 Hz to 20 kHz
- Sensitivity1.4 mV/Pa
| Type | Miniature all-purpose microphone |
|---|---|
| Polar Patterns | Omnidirectional, , or hypercardioid |
| Frequency Response | Omnidirectional: 20 Hz to 20 kHz; Directional: 50 Hz to 20 kHz |
| Sensitivity | 1.4 mV/Pa |
| Overload Sound Level | 150 dB SPL at 1% THD |
| Equivalent Acoustic Noise | Omnidirectional: 25 dBA; Directional: 29 dBA |
| Output Impedance | 600 Ohms +/- 2% balanced, transformerless |
| Powering | 6 V to 50 V phantom at 4 mA (below 24 V reduces overload SPL) |
| Dimensions | 5/16 in x 5/8 in x 5/32 in (8 mm x 16 mm x 4 mm) excluding strain relief |
| Cable Length | 5 ft wireless configurations, 10 ft hardwired configurations |
