Crestron TS-1542-TILT-W-S
The TS-1542-TILT is Crestron's 15.6 inch Full HD touch screen on an integrated tabletop tilt stand, so it sits ready to hand on a conference table, lectern, or desk without a wall cut or separate mount. The 1920 x 1080 capacitive display carries a Smart Graphics control interface and can show up to two live video windows at once from IP cameras, a streaming server, or a DigitalMedia switcher using H.264 or MJPEG.
A single Ethernet run with PoE+ carries control, video, intercom, and power to the panel; where the network does not supply PoE+, the supplied power pack or 24V Cresnet can power it instead. Built-in microphone and speakers support the Rava SIP intercom and on-board voice recognition. This is the white smooth finish; the TS-1542-TILT-B-S is the same screen in black.
| Display | 15.6 in. (396 mm) TFT active matrix color LCD |
|---|---|
| Resolution | 1920 x 1080 pixels, 16:9 Full HD |
| Touch | Capacitive multi-touch, Smart Graphics |
| Video | Dual-window H.264 and MJPEG streaming, up to 25 Mbps combined |
| Audio | Built-in microphone and speakers, Rava SIP intercom, voice recognition |
| Power | PoE+ over Ethernet, or supplied power pack / 24V Cresnet |
| Mounting | Integrated tabletop tilt stand |
| Depth | 1.75 in. (45 mm) |
