Community TRC400 400W 70/100/140V 4-ohm Line Transformer
The Community TRC400 is a 400W line transformer for constant-voltage audio distribution. Its usual job is stepping a 70V, 100V or 140V line down to the voltage and impedance a 4 or 8 ohm loudspeaker needs, and it can also step an amplifier's output up to line level. Three output taps, full, half and quarter power, let each loudspeaker on the line run at the same level as its neighbours or at a different one.
A high-permeability iron core holds up at low frequencies, and response is 50 Hz to 16 kHz within 1 dB with 1.1 dB insertion loss. The frame is open, with four tabs for bolting into a back-box, a loudspeaker enclosure or its mounting hardware, and the 7 in (178mm) colour-coded #18 AWG leads land on terminal strips, solder or wire-nuts.
- Dimensions (H x W x D)3.75 in x 4.5 in x 3.75 in
- Input Type70V, 100V, or 140V line
- Maximum Input70V RMS / 100V peak; 100V RMS / 140V peak
- Output TapsFull power, 1/2 power, 1/4 power
- Output LoadNominal 4 or 8 Ohm
| Type | Line transformer for constant voltage audio distribution lines |
|---|---|
| Power | 400W |
| Input Type | 70V, 100V, or 140V line |
| Maximum Input | 70V RMS / 100V peak; 100V RMS / 140V peak; 140V RMS / 195V peak |
| Output Taps | Full power, 1/2 power, 1/4 power |
| Output Load | Nominal 4 or 8 Ohm |
| Frequency Response | 50 Hz - 16 kHz (+/- 1 dB) |
| Insertion Loss | 1.1 dB |
| Connections | 7 in / 178 mm #18 AWG color coded wires, stripped ends |
| Mounting | (4) mounting tabs each with a 0.44 inch / 11 mm x 0.22 inch / 6 mm hole |
| Dimensions (H x W x D) | 3.75 in (95 mm) x 4.5 in (114 mm) x 3.75 in (95 mm) |
| Weight | 8.9 lbs (4.1 kg) |
