Community Professional Biamp Community TRC400-8 Line Transformer

The Biamp Community TRC400-8 is a transformer built for large-venue and performance systems. Inputs are 8 inches (203mm); #18 AWG color coded wires with stripped ends.

Transformer tap settings are Type: Line transformer for constant voltage audio distribution lines.; Inputs: 70V, 100V; Maximum Inputs: 70V RMS / 100V peak; 100V RMS / 140V peak. Mounting provision: (4) mounting tabs with slotted holes; Hole dimensions: 0.44-inch x 0.22-inch (11 mm x 6 mm).

TransformerType: Line transformer for constant voltage audio distribution lines.; Inputs: 70V, 100V; Maximum Inputs: 70V RMS / 100V peak; 100V RMS / 140V peak
Input TypeInput / Output Connections: 8 inches (203mm); #18 AWG color coded wires with stripped ends
Mounting(4) mounting tabs with slotted holes; Hole dimensions: 0.44-inch x 0.22-inch (11 mm x 6 mm)
Weight8.8 lbs (4.0 kg)
Dimensions (H x W x D)4.3 inches (109 mm) x 5.01 inches (127 mm) x 3.75 inches (95 mm)
