Chief TS325TU Medium Thinstall Dual Swing Arm Wall Display Mount, 25 in Extension

A dual-arm Thinstall for mid-size panels. Closed, it sits 1.8 inches from the wall, which is close enough that it reads as a fixed mount in a finished room; opened, it reaches 25 inches so the screen can be aimed at a second seating area or a kitchen counter.

The install sequence is deliberately one-person: hang the top rail, slide the assembly onto it. After that, 7.5 inches of lateral shift and post-installation leveling roll let you get the picture centred and square without moving the rail. Tilt is -15 degrees. Rated for 32 to 65 inch displays up to 75 lb across dual studs, with in-wall installation possible when a TA500 is purchased with the mount. UL Listed and OSHPD certified.

Display size32 - 65 in (813 - 1651 mm)
Weight capacity75 lb (34 kg)
VESA mounting pattern100 x 100 mm up to 600 x 400 mm
Maximum extension25 in (63.5 cm); minimum depth 1.8 in (4.6 cm)
Lateral shift7.5 in (19.1 cm)
Tilt-15 degrees
Wall stud compatibilityDual stud
CertificationsUL Listed, OSHPD
