Chauvet DJ Gobo Shot

Gobo Shot is a small custom gobo projector built around one practical detail: the gobo door is on the outside. Changing a pattern does not mean opening the fixture or pulling it off the mount, which is what turns a gobo swap between a ceremony and a reception into a one-minute job.

A 32 W cool white LED gives 4,478 lux at 2 m through a 17 degree beam, and manual focus sharpens the image at most throws. A two-way switch controls gobo rotation direction, and a double bracket yoke covers floor and hanging positions. Ten holiday gobos ship in the box. It weighs 3.6 lb, draws 42 W at 120 V, and 14 units power link on one 120 V circuit.

Light Source	1 LED (cool white) 32 W, (2.4 A), 50,000 hours life expectancy
Illuminance	4,478 lux @ 2 m
Beam Angle	17 degrees
Power Linking	14 units @ 120 V; 23 units @ 230 V
Input Voltage	100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current	42 W, 0.6 A @ 120 V, 60 Hz / 51 W, 0.3 A @ 230 V, 50 Hz
Size	7.9 x 4.7 x 9.4 in (203 x 120 x 240 mm)
Weight	3.6 lb (1.63 kg)
