CAD Audio CAD A77 Supercardioid Large Diaphragm Dynamic Side Address Microphone
The A77 is a large-diaphragm dynamic microphone in a side-address body, using a moving-coil motor and supercardioid pattern to reject room noise, which suits it to home studios, podcasting and streaming setups without acoustic treatment. Its size and shape echo the broadcast-style mics streamers favor, without the phantom-power requirement of a condenser.
Max SPL above 150 dB keeps it clean even when a vocalist gets loud, and RoHS-compliant, all-metal construction backs it for daily desktop or stand use.
| Type | Dynamic side-address microphone |
|---|---|
| Polar Pattern | Supercardioid |
| Operating Principle | Dynamic moving coil |
| Frequency Response | 30 Hz - 15 kHz |
| Sensitivity | -48 dBV (3.56 mV) @ 1 Pa |
| Impedance | 500 ohms |
| Max SPL | >150 dB |
| Compliance | RoHS |
