BZBGear BG-8K-DA18 1x8 8K HDMI 2.1 Splitter

The BG-8K-DA18 drives up to eight displays from a single HDMI input at 8K60 4:2:0 12-bit, 4K120 4:4:4 12-bit or 1080p240, on 48 Gbps FRL and 18 Gbps TMDS with HDCP 2.3 and 1.4.

Each output downscales on its own and can convert HDR to SDR, which matters when one older panel in a bank of screens would otherwise show a washed-out picture. EDID management, VRR, ALLM, QMS and QFT are all handled, and firmware updates go in through the USB-C service port.

HDMI Compliance	HDMI 2.1
HDCP Compliance	HDCP 2.3, HDCP 1.4
Video Bandwidth	48Gbps FRL and 18Gbps TMDS
Video Resolution	Up to 8K@60Hz 4:2:0 12-bit, 4K@120Hz 4:4:4 12-bit, 1080p240Hz
Input	1 x IN [HDMI Type A, 19-pin female]
Output	8 x OUT [HDMI Type A, 19-pin female]
Audio Formats	HDMI input/output: LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
Color Depth	8/10/12-bit
