Bose Professional Bose CVT-MA12EX 70V/100V Transformer

The CVT-MA12EX is a 70V/100V transformer for one or two Bose MA12EX column loudspeakers, letting the modules run on a constant-voltage distributed line instead of low-impedance amplifier runs. It includes a bracket that couples the transformer directly to the speaker.

Rated for indoor or outdoor use, it ships with the joining bracket, M6 mounting hardware, and an installation guide.

Compatible With	One or two Bose MA12EX column loudspeakers
Voltage Taps	70V / 100V constant-voltage
Dimensions (H x W x D)	6.5 in x 4.1 in x 5.5 in (165 x 104 x 139 mm)
Colors	Black, White
Application	Indoor or outdoor
Included	Transformer, joining bracket, 4 M6 x 12 mm screws, 4 M6 washers, installation guide
Product Codes	315338-0100 (Black), 315338-0200 (White)
