Avantone Pro CLA-200 Power Amplifier

CLA-200 steps up from the CLA-100 with 200 W per channel into 8 ohms, 300 W into 4 ohms, or 500 W bridged into 8 ohms, still in a Class AB topology for a warmer, more forgiving clip than a Class D design. Frequency response holds 20 Hz to 20 kHz +/- 0.5 dB with distortion under 0.05% and signal-to-noise better than 94 dB unweighted, 103 dB A-weighted.

A damping factor of 250 at 100 Hz into 8 ohms keeps low-frequency control tight on larger passive monitors, and both balanced (20 kOhm) and unbalanced (10 kOhm) inputs are provided. It ships in a 19 inch rack chassis at 3.5 inches tall and 44 lb.

Type	Power amplifier, Class AB
Frequency Response	20 Hz - 20 kHz +/- 0.5 dB
Output Power	200 W @ 8 ohms; 300 W @ 4 ohms; 500 W bridged @ 8 ohms
Distortion	Under 0.05% THD
Signal to Noise	Greater than 94 dB (103 dB A-weighted)
Damping Factor	250 (100 Hz, 8 ohms)
Input Impedance	20 kOhm balanced / 10 kOhm unbalanced
Dimensions	19 in W x 18 in D x 3.5 in H
Weight	44 lb (20 kg)
