AtlasIED SM52T-WH 5.25" 2-Way All Weather Speaker with 30-Watt 70V/100V Transformer (White)
The AtlasIED SM52T-WH is a 5.25" 2-way all weather speaker with 30-watt 70V/100V transformer (white). Environment-resistant SM Series speaker systems offer quality sound reproduction and contemporary styling in a compact enclosure. System components consist of a highly efficient woofer section and FerroFluid cooled, titanium dome high frequency device. The driver is a surface mount.
Vocal and musical clarity is optimized by the mathematically conceived, advanced design of the AtlasIED TRX Control WaveGuide high frequency director. This design provides smooth, even sound coverage (90°H x 90°V). AtlasIED lists 1" ferrofluid™ cooled dome tweeter; 100HR salt spray test per ASTM B117; all ¼"-20 hardware inserts allow easy integration of "off the shelf" security hardware; Atlas sound POLYGUARD™ high frequency circuit diverts damaging transient signals to protect the tweeter. It measures 10 3/16" high, 6 7/8" wide, and 5 7/8" deep. It ships at 8.50 lbs, is safety listed to UL UL 1480A, and carries a manufacturer warranty of 60 months from date of purchase.
| Part Number | SM52T-WH |
|---|---|
| Speaker Type | Surface Mount |
| Sensitivity | 90dB |
| Power Taps | .94, 1.9, 3.7, 7.5, 15, 30 & 6Ω bypass |
| Height | 10 3/16" (28.5 cm) |
| Depth | 5 7/8" (14.8 cm) |
| Width | 6 7/8" (17.46 cm) |
| Shipping Weight | 8.50 lbs (3.86 kgs) |
| Safety Listed | UL 1480A |
| Warranty Period | 60 months from date of purchase |
