AtlasIED FAP42T-B 4" Coaxial In-Ceiling Speaker with 16-Watt 70/100V Transformer and Ported Enclosure - Black

The AtlasIED FAP42T-B is a 4" coaxial in-ceiling speaker with 16-watt 70/100V transformer and ported enclosure - black. FAP42T combines superior coaxial speaker performance with wide dispersion and easy installation. A low profile enclosure and wide coverage make the FAP42T a perfect choice for low ceilings. It runs a coaxial driver over 75Hz - 20kHz.

The FAP42T will satisfy the needs of owners, architects, contractors, and consultants by delivering true, high fidelity sound reproduction in an attractive and easy-to-install system. The FAP42T is ideal for high-intelligibility voice, music, and signal reproduction in commercial, industrial, and institutional applications. AtlasIED lists easy installation in drop tile or sheetrock ceilings via C-ring/V-rail tile bridge and "dog leg" mounting system (included); extended low frequency response from the 285 cubic inch optimally tuned and ported deep drawn galvanized steel enclosure; front mounted tap selector switch for easy system tuning adjustments includes transformer bypass setting for 8 ohm direct coupled operation; perfect companion with the FAPSUB subwoofer system when sub bass is required. It measures 10 1/2" in diameter. It is certified to UL 1480 and carries a manufacturer warranty of 60 months from date of purchase.

Part NumberFAP42T-B
Speaker TypeCoaxial
Sensitivity88dB Average
Power Taps1, 2, 4, 8, 16 Watts & 8Ω
Frequency Response75Hz - 20kHz
Dispersion130
Diameter10 1/2" (26.67 cm)
Certified to Safety ListingUL 1480
Warranty Period60 months from date of purchase
