Audio-Technica System 10 2.4 GHz Digital Wireless System
System 10 runs fully digital on the license-free 2.4GHz ISM band, which sidesteps the TV-channel coordination that UHF wireless requires, and protects the link with three layers of diversity: frequency, time, and space. Every configuration pairs with the same ATW-R1100 receiver, which puts both balanced XLR and unbalanced 1/4-inch outputs on the back panel with independent level control.
The ATW-1101 ships as a body-pack system with no mic, ready for any cW-style locking 4-pin lavalier, headworn, or instrument cable a production already owns. The /G, /H, /H92, and /L variants bundle that same body-pack with a guitar cable, PRO 8HE headworn, PRO 92 lavalier (in black or the beige -TH finish), or a lavalier respectively, and the ATW-1102 swaps the body-pack for a handheld dynamic microphone/transmitter for a presenter who needs to pass the mic around. Up to eight System 10 systems can run in the same room without manual frequency coordination.
| System | 2.4 GHz ISM band (2400-2483.5 MHz), fully digital |
|---|---|
| Diversity | Frequency, time, and space diversity |
| Operating Range | 30 m (100 ft) typical, open range |
| Multi-Channel Capacity | Up to 8 systems simultaneously, no coordination needed |
| Body-Pack Input | Four-pin locking connector (cW-style) |
| Battery Type | Two 1.5V AA (transmitter/handheld), not included |
| Battery Life | >7 hours (alkaline) |
| Receiver Outputs | XLR balanced 0 dBV; 1/4" unbalanced +6 dBV |
