Williams AV Digi-Loop Large Area, Dual Channel Hearing Loop Amplifier

The DL210 NET 2.0 hearing (induction) loop amplifier, designed for large spaces, extends hearing support to those with T-coil-enabled hearing aids and cochlear implants. Its network-control capability provides seamless, remote system set-up, operation, and monitoring via laptop or tablet. The dual-channel capability allows venues to broadcast the audio signal to two separate areas or in phased array designs.

This amplifier is well-suited for areas such as auditoriums and gymnasiums. Ordered as part number DL210NET2.0. Published dimensions, power and warranty are in the specifications tab.

Part Number	DL210NET2.0
Category	Loop Amplifiers, ProAV, Dual-Loop
Dimensions	2 RU Rackmount, 19" W x 3.5" H x 12" D. Chassis is 17" W.
Weight	14.3 lbs (6.5 kg)
Color	Case: Black, white and blue legends on front, white legends on back. LCD: Backlit Blue.
Fan cooling	Variable Speed, Temperature Controlled
Power supply	Internal, Universal 100-240 VAC, 50/60 Hz, 250 Watt. Fuse: 5 x 20 mm, 5 A, 250 V. AC power plug is IEC 320-C14.
Heat output @ 120 VAC	Sleep state: 100 BTU/hr; Idle state: 146 BTU/hr; Driving two loops @ 12 A each: 1,040 BTU/hr
Warranty	2 years
Brand	Williams AV
