Wooden Camera Baseplate System for Sony VENICE/VENICE 2/Rialto
This ARCA baseplate keeps the camera's center of gravity low and spread out so shoulder pads and other accessories mount without hurting stability, and it fits any bridge plate built to ARRI Standard height. Lens-centered front and rear rod clamps take longer rods or rear-mounted accessories, with a double-locking system that resists torque and rotation from lens motors; intuitive access holes let a VENICE build convert to a Rialto 2 setup without pulling the baseplate.
The Rialto/Rialto 2/Rialto Mini baseplate shares the same low-profile footprint and optical center as its VENICE 2 counterpart, so a rig built around one integrates directly with the other's rods, riser, and camera dovetails.
| Camera Compatibility | Sony VENICE, VENICE 2, Rialto, Rialto 2, Rialto Mini |
|---|---|
| Weight (VENICE kit) | 759 g (1.7 lb) |
| Weight (Rialto kit) | 431.5 g (1 lb) |
| Dimensions (VENICE kit) | 400 x 50 x 147 mm (15.7 x 1.97 x 5.8 in) |
| Bridge Plate Interface | ARRI Standard height, any compatible bridge plate |
| Rod Clamps | Front + rear, double-locking, lens-centered |
| Convertibility | Access holes allow VENICE-to-Rialto 2 conversion without removal |
