Wooden Camera 3/8"-16 Accessory Cube
The 3/8"-16 Accessory Cube provides five sides of 3/8"-16 mounting points for attaching accessories to any 1/4"-20 or 3/8"-16 mounting point. Two detachable locating pins are used to prevent twisting. The 3/8"-16 locating pins are compatible with any ARRI-standard mounting point. The 1/4"-20 locating pins are compatible with both Wooden Camera and ARRI-standard mounting points. 3/8"-16 Accessory Cube Weight: 30.5 g (0.067 lbs) Dimensions: 25.4 x 25.4 x 25.4 mm (1 x 1 x 1 in)
G&G stocks it in 2 versions: 3/8"-16 Holes, 1/4"-20 Screw, 3/8"-16 Holes, 3/8"-16 Screw. It weighs 30.5 g (0.067 lbs) and measures 25.4 x 25.4 x 25.4 mm (1 x 1 x 1 in). It mounts via 1/4"-20, 3/8"-16.
| Type | Utility |
|---|---|
| Weight | 30.5 g (0.067 lbs) |
| Dimensions | 25.4 x 25.4 x 25.4 mm (1 x 1 x 1 in) |
| Mounting / Interface | 1/4"-20, 3/8"-16 |
| Compatibility | any ARRI-standard mounting point |
| Available Versions | 3/8"-16 Holes, 1/4"-20 Screw, 3/8"-16 Holes, 3/8"-16 Screw |
| Manufacturer Part Number | A00129, A00130 |
