Teradek Antenna Array for Bolt 6 and Bolt 4K

The Antenna Array is what you fit when the Bolt link has to hold across a stadium, a car park or a stage full of competing radio. It focuses the signal into a directional cone and cuts the interference the receiver has to reject, which is how a Bolt 6 or Bolt 4K reaches its full 5,000 ft rather than what the venue will allow.

It is a 5.1 - 7.3 GHz MIMO panel built from three 16 dBi elements, two 14 dBi elements and one 2 dBi omnidirectional element. That last one matters: it keeps reception alive when the transmitter wanders outside the panel's cone. The housing is UV-protected plastic over an aluminium alloy frame, and it is available on a gold mount or a V-mount plate.
