SWIT S-4611 SDI to DVI Converter

The S-4611 converts a 3G/HD/SD-SDI source up to 1080p60 into DVI-D (18+1), the format most confidence monitors, house TVs, LED boards and projectors outside a broadcast rack still expect. A reclocked SDI loop output passes the same signal on to a second downstream destination, so the converter does not dead-end the SDI chain.

Embedded SDI audio channels 1 and 2 come out as analog on a 3.5mm headphone jack at 48kHz, giving the DVI destination sound without a separate audio path. The heavy-duty aluminum housing includes 1/4-20 threads on the bottom for mounting to a camera or rig, and it runs from the same 6-18V pole-tap power as the rest of SWIT's mini converter line.
