Panasonic PT-CMZ50U Ultra Short-Throw Laser Projector
The PT-CMZ50U is an ultra-short-throw laser projector built for classrooms and meeting rooms. Its fixed lens throws a WUXGA (1920 x 1200) image at a 0.235:1 throw ratio, so an 80-inch picture forms with the cabinet roughly 1 cm from the wall, keeping the beam out of a presenter's eyes and the shadow off the screen.
A laser phosphor light source rated up to 20,000 hours removes lamp changes, and 5,200 lumens with a 3,000,000:1 contrast ratio holds up with the room lights on. Quiet Mode drops operating noise to 25 dB for small spaces. Connections include HDMI with CEC, an HDMI output for daisy-chaining, USB Type-A and RS-232C control. This is the white-cabinet model.
| Resolution | WUXGA (1920 x 1200) |
|---|---|
| Brightness | 5,200 lm |
| Contrast Ratio | 3,000,000:1 |
| Light Source | Laser phosphor, up to 20,000 hours (24,000 in Eco) |
| Lens | Fixed, powered focus, F 1.7, f 2.81 mm |
| Throw Ratio | 0.235:1 (16:10) |
| Operating Noise | 25 dB (Quiet mode) |
| Connectivity | HDMI (CEC), HDMI OUT, USB Type-A, RS-232C |
| Cabinet Color | White |
