Panasonic AW-HE42K HD PTZ Camera (Black, Demo)
This is a demo AW-HE42K, a Full HD integrated pan/tilt/zoom camera built on a 1/2.3-type MOS sensor and a 20x optical zoom lens, with intelligent zoom to 30x and a 1.4x digital extender for reach in large rooms. It pans ±175 degrees and tilts from -30 to +90 degrees, stores presets for repeatable framing, and includes a built-in four-stage ND filter to hold exposure under bright stage or window light. The matte black body suits dark stage sets and studio walls.
The HE42 outputs simultaneously over 3G-SDI, HDMI, IP, and USB, so it can feed a production switcher, a streaming encoder, and a soft codec at once, with a mic/line audio input and SD card recording on board. It runs on PoE+ for single-cable installation or on 12V DC from the AC adapter. This unit ships as a demo backed by a Panasonic parts and labor warranty; pair it with an AW-RP150 or AW-RP60 controller for joystick pan, tilt, zoom, and focus.
| Image Sensor | 1/2.3-type MOS |
|---|---|
| Optical Zoom | 20x (intelligent zoom to 30x, 1.4x digital extender) |
| Pan Range | ±175° |
| Tilt Range | -30° to +90° |
| Video Output | 3G-SDI, HDMI, IP, USB (simultaneous) |
| Audio Input | Mic/Line |
| Recording | SD memory card |
| ND Filter | Built-in 4-stage |
| Power | PoE+ or 12V DC |
