Ikan Tally Router for ATEM Switchers up to 8 Cameras
The Ikan TI-ATM-8 is the Ikan Tally Router for ATEM Switchers up to 8 Cameras. Ikan's own feature list covers Eight output ports to connect to Ikan monitor tally system, Compatible with standard ethernet cables, and Direct connection to Blackmagic GPIO Tally Interface.
Published figures include input connector of DB9; output connectors of 4x RJ45; length of cable (end to end) of 41"; build material of Aluminum. Ikan also lists Includes power adapter and ATEM connection cable and Plug-and-play setup. In the box: 2x Tally Router, 1x Switcher Connection Y Cable.
| Input Connector | DB9 |
|---|---|
| Output Connectors | 4x RJ45 |
| Length of Cable (end to end) | 41" |
| Build Material | Aluminum |
| SI Technical Guide | Wiring Diagram |
| Product Weight | 1 lbs. |
| Product Dimensions | 3.25" x 4" x 1.33" |
| Included | 2x Tally Router, 1x Switcher Connection Y Cable |
| Model | TI-ATM-8 |
