FXLION 4 CH Smart Charger - 16.8V / 4A Gold-Mount
The PL-Q4AL is FXLION's four-channel smart charger for 14.8V Gold-Mount batteries. With SMBUS batteries that report their data, the display shows the capacity percentage, capacity, charging voltage and current, remaining charge time and cycle count, which makes it easy to spot a pack that is wearing out; with other batteries it shows voltage, current and capacity.
All four channels charge at once at 16.8V / 4.0A (each channel). Mains input is 100-240V 47-63Hz, which is wide enough to travel between regions, and power draw is 300W. The unit measures 281 x 128 x 191 mm and weighs 2470 g. In the box: 1 x PL-Q4AL, 1 x power cable.
- Dimensions281(L)mm*128(W)mm*191(H)mm
- Channels4, simultaneous
- Input100-240V 47-63Hz
- Output16.8V / 4.0A (each channel)
- Power Draw300W
| Input | 100-240V 47-63Hz |
|---|---|
| Output | 16.8V / 4.0A (each channel) |
| Power Draw | 300W |
| Features | supports SMBUS compatible battery information, also simultaneous charging |
| Dimensions | 281(L)mm*128(W)mm*191(H)mm |
| Weight | 2470g |
| Included | 1 x PL-Q4AL, 1 x power cable |
| Manufacturer Part Number | PL-Q4AL |
| Display | Capacity %, capacity, voltage, current, time remaining, cycles (SMBUS) |
| Channels | 4, simultaneous |
