Elation EP4 DMX Data Distribution Node

The Elation EP4 is a DMX data distribution node from Elation. Rated width: 118 mm (4.6 in.). Rated height: 42 mm (1.65 in.).

Power consumption is quoted at 3.8W. Listed length: 133.5 mm (5.3 in.). Ordering code EP4.

Length	133.5 mm (5.3 in.)
Width	118 mm (4.6 in.)
Height	42 mm (1.65 in.)
Weight	0.5 kg (1.1 lbs)
Usb-C 5V	POE 802.3af
Power Consumption	3.8W
Ce / Ip20	Ordering, Included Items, Universal 5V/2A USB Power Adapter (UK, US, Europe, AUS connectors), 100-240V, 1.5m Obsidian USB-C cable, (2) Wallmount plates, DIN-Rail clamp
Features	Standalone; Truss-mount (M10 or M12 mounting hole); Wall-mount horizontal or vertical (included); DIN Rail horizontal or vertical (included); Connections; (4) 5pin DMX/RDM optically isola...
