Dynacord PowerMate 2200-3 22-Channel Compact Power Mixer

The PowerMate 2200-3 folds six devices into a single 22-channel chassis: mixing console, two effects units, graphic equalizer, USB audio interface and power amplifier.

The mixing section starts at discrete low-noise microphone preamps, with three auxiliary busses of which one is switchable pre/post fader for monitor work. The two effects processors carry 100 factory presets, including the PowerMate reverbs, and each can be edited and stored to 20 user memories. The built-in USB interface shares four playback and four recording channels at 24-bit/96 kHz with MIDI. A cover lid is included.

, switchable in groups48 V DC
Channels (Mono + Stereo)18 + 4
Auxiliarys (MON, FX, AUX)2 Pre, 2 Post, 2 Pre/Post switchable
POWER AMP INPUTS to Speaker L/R outputs< 0.075%
DIM 30, power amplifier, 3.15 kHz, 15 kHz< 0.05%
IMD-SMPTE, power amplifier, 60 Hz, 7 kHz< 0.15%
Any input to Speaker L/R output20 Hz to 30 kHz
Mute- & Standby-Switch attenuation> 100 dB
Weight18 kg
Mic preamp gain0 dB to +60 dB
Phantom power+48 V
