Crestron AMP 3210T
The Crestron AMP-3210T is a three-channel commercial power amplifier with outputs that switch between low-impedance and constant-voltage operation. Each channel is rated for 210 watts at 4 ohms, 120 watts at 8 ohms, or 210 watts at 70V or 100V, and channels 1 and 2 can be bridged for 420 watts into a single 8 ohm load.
The 70/100V outputs are transformer isolated to carry long and complex distributed-speaker runs, while the low-impedance path serves nearby stereo or mono loads. The amplifier is ENERGY STAR qualified with convection cooling and an auto power-down mode for low idle consumption. The 1U chassis stands free or mounts in a 19-inch rack with the included adhesive feet and rack ears.
| Channels | 3 (channels 1-2 bridgeable) |
|---|---|
| Output Power | 210 W per channel at 4 ohms; 120 W at 8 ohms; 210 W at 70V or 100V; 420 W at 8 ohms bridged (ch 1-2) |
| Frequency Response | 20 Hz to 20 kHz +/-0.5 dB at 4/8 ohms; 80 Hz to 20 kHz +0/-3 dB at 70/100V |
| THD | 0.05% at 1 kHz, full rated power |
| 70/100V Output | Transformer isolated |
| Compliance | ENERGY STAR qualified |
| Dimensions | 1.70 x 17.28 x 14.59 in (1U) |
| Weight | 17.8 lb |
