Community HSB-BFR22 I SERIES Dual Horizontal Splay Kit
The Community HSB-BFR22 hangs two full-range 2-way I SERIES loudspeakers side by side in portrait orientation and splays them apart to widen the horizontal coverage. It suits the 1122 and 1152 models and flies from a pair of 22-inch BalancePoint fly rails.
The kit is the two rails, a splay adapter plate, four cabinet brackets and two preassembled hinges, 25 lb (11.3 kg) in all. The angles stamped on the hinge are the splay between the adjacent cabinet sides, not the centre-to-centre aiming angle. A third cabinet can join the array with an HVS kit. Community rates each I SERIES rigging fitting at 150 lb (68 kg) WLL with a 10:1 safety margin. Black and white versions are stocked, with a 5-year warranty.
- Kit Weight25.0 lb
- Finish OptionsBlack, White
- TypeDual horizontal splay kit for 2-way loudspeakers
- FitsCommunity I SERIES 2-way IP6/IP8-1122 and IP6/IP8-1152
- Parts22-inch BalancePoint fly rails (2), splay adapter plate (1)
| Type | Dual horizontal splay kit for 2-way loudspeakers |
|---|---|
| Fits | Community I SERIES 2-way IP6/IP8-1122 and IP6/IP8-1152 |
| Parts | 22-inch BalancePoint fly rails (2), splay adapter plate (1), cabinet brackets (4), hinge brackets (2 preassemblies) |
| Kit Weight | 25.0 lb (11.3 kg) |
| Fitting Rating | I SERIES rigging fittings: 150 lb (68 kg) WLL, 10:1 safety margin |
| Finish Options | Black, White |
| Warranty | 5 years |
| Compliance | Compliant with the US Trade Agreement Act (TAA) |
